S154 LED Stalk Spotlight - 1W @ 350mA | 1.5W @ 500mA
-
Overall Height - Made to measure (100mm to 1075mm)
-
Fixing - Various fixings available
-
Beam Angle - Various lens options available
-
Finish - Various colour options available
-
CCT - Various LED options available
-
5 Year Replacement Warranty.
Spectrum LED Lumen Output:
Display Lighting are pleased to announce that all Spectrum LED Spotlights (V4) are manufactured with integrated CREE LEDs and all achieve a CRI rating of 90 or above including 5000K.
-
3000K - 124lm @ 350mA (CRI90>)
-
4000K - 124lm @ 350mA (CRI90>)
-
5000K - 124lm @ 350mA (CRI90>)
Spectrum LED Spotlights can also be operated from remote batteries, "click here" for details.
|
 Adjustment - 90 Degrees Beam Angle - 45 Degrees Cut Out - ** OPTIONS AVAILABLE ** Dimmable - 1-10V / Triac Finish - ** OPTIONS AVAILABLE **
 Fixing - ** OPTIONS AVAILABLE ** Height - Made to measure IP Rating - IP20 Lamp - Non Replaceable LED LED Colour - ** OPTIONS AVAILABLE **
 Material - Brass / Aluminium QTY per pack - 1 Rotation - 350 Degrees Voltage - 350mA Wattage - 1W @ 350mA | 1.5W @ 500mA
|
1. SPOTLIGHT HEIGHT:[click to expand]
Manufactured to your exact specified height, enter the visible overall height required in the box shown below:
2. SELECT COLOUR TEMPERATURE (CCT):[click to expand]
The light produced by candles is very warm (basically yellow/orange) whereas daylight at noon is very cool. The colour or warmth of white light is ranked on a scale, the Kelvin scale, the warmer the colour the lower the colour temperature. Candles being around 2000 degrees Kelvin (K) while daylight typically 5500 – 6500K, please select your choice of colour temperature from the list below:
3. SELECT FIXING:[click to expand]
To make your product specification please make a selection from the component list provided:
4. SELECT BEAM ANGLE REQUIRED:[click to expand]
When selecting beam angle, it’s important to note how many different fixtures you have to work with, as well as the distance between these light sources. Think about whether you want overlapping beams to create general lighting and ambience, or whether you’d prefer isolated pockets of light. This is especially important if you are working with overhead recessed lighting.
5. SELECT FINISH:[click to expand]
To make your product specification please make a selection from the component list provided:
COLOURS SHOWN ARE EXAMPLES ONLY AND MAY NOT BE AN EXACT MATCH FOR FINISHED PRODUCTS. TO VIEW RAL COLOUR CHART CLICK HERE
6. NUMBER OF LUMINAIRES REQUIRED PER SET *WIRED TO ONE POWER SUPPLY*[click to expand]
Please select how many fittings you would like to operate per set (from a single power supply) with Plug & Play Connections. If your requirement is not shown in the list please add a note to your quote request or contact one of our sales team on 0044 (0) 161 207 3355 or email sales@display-lighting.com
7. SELECT LED DRIVER / DIMMING OPTION:[click to expand]
Select from the Plug & Play options below, if your requirement is not shown in the list please add a note to your quote request or contact one of our sales team on 0044 (0) 161 207 3355 or email sales@display-lighting.com
Casambi Smartphone App required for Bluetooth control (available on IOS & Android)
|
